AC Spark Tester1
Teleflex Elektronik Covers the method for AC spark testing of insulation and non-metallic sheath of electric cables. It is used for evaluation of insulating and sheathing materials for specific end uses and as a means for detecting defects in the manufacturing processes.
Key Highlights
- LINE SPEED UPTO TO 400 m/min
- THREE MODELS ARE AVAILABLE OF 0-15/25/30 KV AC
- STAINLESS STEEL ELECTRODE HEAD
- HINGED BEAD CHAIN ELECTRODES
- BEAD CHAIN ELECTRODES ARE DESIGNED TO LIFT AWAY FROM CABLE WHEN THE UNIT LID IS OPENED
- PROVIDED WITH LIMIT SWITCH FOR OPERATOR SAFETY AND WARNING LAMP
- WATER DRAINAGE FACILITY
- FLOOR MOUNTED GAUGE HEADS WITH HEIGHT ADJUSTMENT
- HEAVY DUTY AIR / OIL COOLED HIGH VOLTAGE TRANSFORMER
- FAULT REGISTERING METER
- AUDIO ALARMING WITH WARNING LIGHT
- FULL FEATURED CONTROL PANEL
Specification
- Input Voltage: AC 230 Volts 50 Hz.
- Out Put Voltage: 0-15 KV/0-30 KV
- Out Put Frequency: 50 Hz.
- Front Penal Controls: Mains On-Off Switch, soft HT ON-OFF push buttons, Fault Counter, Set KV Knob, Extrusion/Rewind Switch.
- Indicators: Analog KV Meter, Fault Indicator.
- Electrode Type: Hinged Bead Chain.
- Max. Line Speed: 400 m/min.
- Max. Electrode Dia.: 150X150 MM.
- Fault Counter: Impulse Type Incremental and resettable.
- Mode of operation: Continuous HV [Extrusion Mode].
- At onsite: Test Volt interrupted on fault [Rewind Mode].
- Mounting Height: 1Mtr. Adjustable +/- 10%.
- Safety: Limit Switch on Electrode Box Top opening Lid.
- Finish: Enameled Paint.
